CLI for F4 1S 5A Flight Controller BMI270 (BLUEJAY ESC) 2022

The lastest F4 1S 5A AIO Brushless Flight Controller contains ELRS V2.0 & Frsky V3.0 version.

ELRS (It is also fit for Meteor 75 ELRS 2.4G):

Basic firmware: BETAFPVF411_4.3.0

   Note: Previous version of firmware does not support BMI270 Gyroscope.

No need to flash configuration firmware (including CLI configuration)

BETAFPVF411_Meteor75_ELRS V2.0_BLUEJAY.hex

CLI for quadcopter (Do not need to be flashed separately):

BTFL_cli_Meteor75_ELRS v2.0_BLUEJAY.txt

Frsky (It is also fit for Meteor75 Frsky & TBS ):

Basic firmware: BETAFPVF411RX_4.2.11

No need to flash configuration firmware (including CLI configuration)

BETAFPVF411_Meteor75_Frsky_BLUEJAY.hex

BETAFPVF411_Meteor75_TBS_BLUEJAY.hex

CLI for quadcopter (Do not need to be flashed separately):

BTFL_cli_Meteor75_Frsky_BLUEJAY.txt

BTFL_cli_Meteor75_TBS_BLUEJAY.txt

F4 1S 5A FC is also fit for Meteor 65, Meteor 65 Pro, please download the corresponding CLI.

CLI for Meteor 65 (2022)

CLI for Meteor 65 Pro (2022)

Firmware for ESC (Bluejay 96KHz)

A_X_5_96_20221108.hex

Note: Use the ESC Configurator - for Bluejay  &  BLHeli_S and AM32 (esc-configurator.com) to set

         the motor rotation,others (such as starting power and so on.) have been written into the firmware, no

         need to set.
